BLACK RHINO Series Shale Shaker

Pub Date:Jan 29, 2018    |    Views:81    |

KOSUN BLACK RHINO Series Shale Shaker is the first-stage solids control equipment in the drilling fluid solids phase control system, and separates a large amount of cuttings carried by mud from wellhead, facilitating mud to enter the second-stage separation equipment. The shale shaker can be used separately, or be combined by double or multiple ones, and our company can provide corresponding diversion manifold.


Black Rhino Shale Shaker.jpg


KOSUN BLACK RHINO Series Shale Shaker is a high frequency linear-motion vibrating screen machine, equipped with three screen panels and two vibrating motors, and offering a choice of manually adjusting screen frame angle while drilling (AWD). When KOSUN BLACK RHINO Series Shale Shaker works, the screen frame angle can be adjusted from -1° to +5° by dint of innovation of its structural design.

KOSUN BLACK RHINO Series Shale Shaker can separate drilling cuttings efficiently. Fix vibrating motors onto a high-strength supporting beam of screen frame, and position them on the screen bed, and the positioning in this way can make vibrating motors directly exert G-forces on screens. The isolation mounts can protect the bedframe from vibration effect of the screen frame. The screen bed humps slightly in favor of tensioning screens. This method of tensioning screens can enhance performance and service life of screens. Mud is fed to KOSUN BLACK RHINO Series Shale Shaker via the collection pan of desilter and desander or via the feeder.

Major components of KOSUN BLACK RHINO Series Shale Shaker include screen frame, vibrating motor, screen tensioning system, AWD, locking device, feeder, electrical system, etc. This manual will describe these components respectively.
